Automatic Metal Tinplate Can Bucket Filling&Capping Machine for Coating Emulsion

Product Description

Specially designed for the need of frequent replacement of packing specifications, Using the latest European weighing technology, Siemens programmable microcomputer controller, automatic feeding speed adjustment, automatic feeding accuracy correction, emergency stop/power off/remove triple protection. Set various packing specifications, store over 30 kinds of packaging specification data, super differential automatic alarm, automatic gland system, and equipped with explosion proof equipment. The equipment is applied to the products of coating, ink, resin, emulsion, universal glue and other viscosity less than 50000 CPS.

1. Adopting the latest weighing technology in Europe

2.Taida programmable microcomputer controller

3.Automatic discharge speed adjustment

4.Automatic discharge accuracy correction

5.Emergency stop, power failure, triple protection

6.Set various packaging specifications

7.Equipped with explosion-proof device ect.


Introduction of latex paint filling machine

We specialize in the production of automatic paint filling machine, latex paint filling machine, edible oil filling machine, waterproof resin filling machine,

Solvent filling machine, real stone paint filling machine, waterproof paint filling machine, floor paint filling machine, lubricating oil filling machine

Antiseptic filling machine, thinner filling machine, curing agent filling machine, putty paste filling machine, varnish filling machine,

All fluid material filling equipment such as oil filling machine, paint filling machine, etc.

The filling machine is a kind of precise measurement intelligent equipment, and it also has a variety of mechanical cooperative execution functions. It is convenient, fast, efficient, accurate, and the packaging barrel mouth is clean and tidy.

Convenience: Low requirements on the site and low requirements on the educational level of the operators

Fast and efficient: 30% higher than traditional manual packaging

Labor intensity: 50% lower than traditional manual packaging

Accuracy: Usually positive and negative error 2-10 grams (traditional manual packaging error 50-100 grams)

Clean and tidy: the filling head is not dripping, leaking or splashing. (For eccentric small barrels that require high curing agents, resins, automotive paints, motor oils, and P∪ court paints)

Features of waterproof paint filling machine

Easy operation: digital input to set weight; 10 kinds of formula storage;

Function switching: Net weight/gross weight type, automatic/manual type and other function switching modes for easy selection;

Intelligent and efficient: automatic zero tracking; tare weight detection and full-range barrel filling; automatic induction capping;

Accurate and fast: two-speed filling device; automatic feeding speed adjustment; automatic correction of accuracy;

System protection: Emergency stop protection device; factory settings can be restored by misoperation;

Import configuration: Swiss original METTLER TOLEDO high-precision digital instrument, Japanese OMRON relay, Taiwan Weilun touch screen, Taiwan original Yadeke actuator, cylinder, to ensure the overall performance of the equipment is stable, durable.

Explosion protection: overall aluminum alloy explosion-proof electrical control box, explosion-proof grade: Exd II BT6;

Operating procedures:

Manual barrel placement ---automatic tare weight detection---automatic filling---manual capping---automatic capping---operation completed

Product Parameters

Rotating design, single person operation, automatic quantitative filling, automatic capping, capping, automatic positioning and capping, simple and convenient interface operation.
